Rack Mounted Lifepo4 Battery

MECC 48V 100AH Racked Mount lithium battery Rack-Mounted Lithium Battery Overview Rack-mounted lithium batteries are designed for efficient energy storage and management in various applications. These batteries offer high energy density, long cycle life, and fast charging capabilities, making...

MECC 48V 100AH Racked Mount lithium battery

Rack-Mounted Lithium Battery Overview

Rack-mounted lithium batteries are designed for efficient energy storage and management in various applications. These batteries offer high energy density, long cycle life, and fast charging capabilities, making them ideal for renewable energy systems, data centers, and industrial use. Their modular design allows for easy installation and scalability, ensuring reliable power supply and optimal performance.

One of the key features of rack-mounted lithium batteries is their high energy density. This allows them to store more energy in a smaller footprint, making them space-efficient. Additionally, these batteries are highly efficient, converting stored energy into usable power with minimal loss, ensuring maximum utilization of energy resources.

Rack-mounted lithium batteries are known for their long cycle life, often exceeding thousands of cycles without significant degradation. This durability makes them a cost-effective solution for long-term energy storage needs, reducing the frequency of replacements and maintenance.

Support high discharge power. IP20, natural cooling, wide temperature range: -20 to 55 degree .
Modular design, easy to expand, Max.64 units in parallel, Max. capacity of 327kwh.

1 -

001

002

2 -

003 -

	MECC-51.2-100		45
			5LED(SOC:20%~SOC100%),3LED (working, alarming, protecting)
	LiFePO4		IP20
	100		Charge: 0-55 degree ( Optional heating: -20 degree ~55 degree ), Discharge: -20 degree -55 degree
	Max. 64 pcs pack (327kWh) in parallel (Max. 32 pcs no external setup)		0 degree -35 degree
	51.2		5%~95%
	43.2~57.6		Less than or equal to 2000m
	5.12		Greater than or equal to 6000(25 degree ±2 degree ,0.5C/0.5C,90%DOD,70%EOL)
	4.6		Wall-Mounted, Floor-Mounted, Rack-Mounted (19-inch standard cabinet, cabinet depth Greater than or equal to 600mm )
	Recommend 50		CAN2.0, RS485
			10 years
	90%		16MWh@70%EOL
	440133540		UN38.3, IEC62619, CE,UK, VDE2510-50, CEI 0-21, FCC, UL1973, UL9540A

product-1500-527

product-1500-723

What is a rack-mounted lithium battery?

A rack-mounted lithium battery is a type of energy storage system designed to be installed in a rack or cabinet. It is commonly used in data centers, renewable energy systems, and industrial applications to provide reliable power backup and energy management.

How does a rack-mounted lithium battery work?

Rack-mounted lithium batteries store electrical energy and release it when needed. They use lithium-ion technology, which allows for efficient energy storage and quick discharge. These batteries can be charged from renewable sources or the grid and provide power during outages or high demand.

What are the benefits of using a rack-mounted lithium battery?
